Haklift

One-wheel pulley block with base attachment. Equipped with slide bearings.



  • Material: Steel
  • Marking: CE-marked
  • Finish: Electro galvanized / painted black
    Select a row from the table below, then click the add to quote button
    Part Code WLL
    ton
    Max rope Ø
    mm
    A
    mm
    B
    mm
    C
    mm
    D
    mm
    E
    mm
    F
    mm
    G
    mm
    H
    mm
    I
    mm
    K
    mm
    Weight
    kg
    46100016F 0,5 8 120 60 78 100 90 30 8 60 20 10 1,5
    46100017F 1 10 140 60 98 125 110 35 10 77 25 12 2,4
    46100032F 2 12 180 80 118 150 140 40 12 92 30 14 4,5
    46100035F 3 16 230 100 160 200 180 50 15 120 35 18 8,2
    46100027F 5 20 320 120 225 275 260 60 20 165 40 23 18
